GDM-211-B-11 – Hirschman DIN (Black)
$27.00
| Housing Color / Material | Black / Fiberglass Reinforced Plastic |
| Type of Contact / Material | Screw / Sn |
| Contact Spacing | 18 mm |
| Cable Entry / Range | PG 11 / 4.5 to 11 mm |
| Max Voltage / Current | 250 V / 16 amps |
| Number of Poles | 2 Poles + Ground |
| Maximum Conductor Size | 16 awg |
| Fixing Screw | M3 x 35 mm |
| Gasket | NBR Profile |
| Operating Temperature | – 40 F to + 257 F |
| Protection Class | IP 65 |
| Approvals | UR, VDE, SEV, CSA, CE, ROHS |
11329 in stock
Product Description
Click here for catalog and specifications.
US Customs Harmonized Code: 8536.69.4040
Country of Origin: Japan
Weight: 0.5 lbs
Additional Information
| Weight | .02 lbs |
|---|---|
| Dimensions | 2 × 2 × 1 in |
